XF 3111 Green Roof Draining Solutions

XF 3111 is one of a new generation of environmentally conscious synthetic products. This drainage composite consists It consists of a post-industrial recycled white polypropylene drainage core and a very strong but lightweight white Colback®

filter fabric thermally bonded to one side. The U groove entangled filament configuration is protected from UV degradation for up to 30 days. This product, with 40% post- industrial recycled content, can help contribute up to 2 LEED points when used in conjunction with other recycled content products. XF 3111 can contribute towards additional LEED points when used with a green roof by reducing storm water runoff, heat islands and energy consumption.

Applications for XF 3111

 Extensive, semi-intensive and intensive green roofs
 Exterior and interior planters
 Enhance water retention and storm water management capacities of green roofs
 Suitable for conventional protected membrane roofs (PMR)

Are these the features and benefits you need for your green roof draining product?

 Excellent durability
 Reflects heat to prevent insulation board warping & membrane softening during construction
 Continuous flow in all directions, even under high loads
 Protects waterproofing during construction
 Conforms to irregular surfaces and corners
 Long rolls reduce installation costs by reducing butt seams and eliminating interlocking
 Recycled content polymer contributes towards LEED points
 3” fabric overlap flap

How to install XF 3111

Install XF 3111 with the water retention fleece facing up and entangled filaments down. Butt rolls and cover joint with adjacent roll using the built-in 4in. (100mm) side lap to achieve a continuous fleece coverage. Butt ends of rolls together. Stagger adjacent rolls by at least 40 in. (1m) so end joints are not aligned. Cover XF 3111 immediately after installation to prevent wind uplift and degradation by ultra-violet radiation.

Technical Data

To the best of our knowledge, the information contained herein is accurate. However, Low & Bonar Inc. and Global Plastic Sheeting Inc. cannot assume any liability whatsoever for the accuracy or completeness thereof. Final determination of the suitability of any information or material for the use contemplated, of its manner of use and whether the suggested use infringes any patents is the sole responsibility of the user. These products may be covered by patents or patents pending.
