GPS Diamond Scrim 30, 36, 45 mil- Heavy Duty LLDPE Liner

GPS Diamond Scrim is composed of two heavy sheets of impermeable, high strength LLDPE extruded on both sides of a high tensile strength scrim-reinforcing layer. This composite membrane has an excellent combination of flexibility and tensile strength. Its optional gray upper surface reduces heat buildup compared to a standard black material and is less reflective than a white liner in bright environments. The opaque black underside of the liner prevents sunlight penetration and UV transmission. Raw materials are produced 142” in width to minimize the seams required.

EPA Regulations enacted in May 2015 require the use of geomembrane liners and caps for the disposal of coal ash. GPS geomembranes meet or exceed GRI GM13 and GM17 standards and are available in large rolls to expedite deployment. We also offer interim covers and lightweight rain-shed covers, fabricated to any size.

An optional textured surface improves traction and increases friction for improved slope stability and onsite safety.

Download Data Sheet Here

Common Applications:

Reserve Pits
Coal Ash
Environmental Caps
Frac Pits
Under Rig Liners
Retention Ponds
Fresh Water Pits
Flowback Pits
Secondary Containment
Aboveground Storage Tanks

Specifications:

Properties	Test Method	Frequency	Minimum Average Values
			H30	H36	H45
Thickness, Nominal (mils) Min. Ave. (mils)	ASTM D5199	Per Roll	30 27	36 32	45 40
Weight Nominal (lb/1000, ft²) Min. Ave. (lb/1000, ft²)	ASTM D5261	Per Roll	140 125	168 151	210 189
Grab Tensile Strength (lb), min. ave. Elongation (%), min. ave.	ASTM D7004 (each direction) (each direction)	30,000 lb	300 25	310 25	310 25
Tongue Tear (lb), min. ave.	ASTM D5884 (each direction)	30,000 lb	130	130	130
Index Puncture (lb), min. ave.	ASTM D4833	30,000 lb	85	103	105
Ply Adhesion (lb), min. ave.⁽¹⁾	ASTM D6636	35,000 lb	20	25	25
Oxidative Induction Time (OIT)⁽²⁾ (a) Standard OIT or (b) High Pressure OIT	ASTM D3895 ASTM D5885	Formulation	>100 >1000	>100 >1000	>100 >1000
Standard Roll Dimensions
Roll Length⁽³⁾, ft			11.83	11.83	11.83
Roll Length⁽³⁾, ft			1500	1230	1000
Roll Area, ft⁽³⁾			17,745	14,551	11,830

(1)Alternatively, an acceptable ply adhesion is to have a film tearing bond occur within the sheet material.
(2)The Manufacturer has the option to select either one of the OIT methods listed to evaluate the
antioxidant effectiveness in the geomembrane.
(3)Roll widths and lengths have a tolerance of +/- 1%
*Custom material thicknesses also available
This data is provided for informational purposes only. Global Plastic Sheeting makes no warranties as
to the suitability of the fitness for a specific use or merchantability of products referred to, no guarantee of satisfactory results upon contained information or recommendations and disclaims all liability from resulting loss or damage. This information is subject to change without notice, please check with Global Plastic Sheeting for current updates.
This is a preliminary data sheet based upon laboratory testing of initial manufacturing lots and may be changed without notice as additional product testing data becomes available.
