Enkamat & Enkadrain-: Only Drainage On Market that qualifies for Leeds Points-recycled poly drainage fabric

 Enkamat 7010 for Erosion Control

Enkamat erosion control 7010

Enkamat 7010 is permanent erosion control protection mat that is made of monofilaments which are fused together where they cross. It is a flexible three dimensional open structure which allows for 95% of the volume of the mat to be available for soil filling.  These features allow for positive integration and immediate stabilization of the soil sloped surfaces while providing an enhanced environment for seed germination.

Even before the vegetation develops, Enkamat 7010 offers immediate protection against erosion.  The way the mat is built allows it to reduce the impact of wind and water on the surface thus preventing soil runoff.  There is a biodegradable backing stitched to Enkamat 7010 that offers extra protection at this stage.

Size:  39" x 200' rolls  Buy Coldbond now

Enkamat 7008/7010-Metal & Wood Shingle Roofs

 7010 EnkamatEnkamat 7008/7010 is a three-dimensional, multi-use mat, made of continuous nylon filaments fused at their intersections.  It can be used in ballasted and metal roofing applications as well as on wood shingle roofs where spacing of the roof will provide the ventilation and drainage needed for a long service life.  The nylon filaments do not fall under the load of the roof and the rigors of the construction environment, including construction foot traffic.  The space between the roof membrane/weather barrier under layment and the ballast/metal roof will allow any moisture to flow away or evaporate.  Best used with zinc roofs.  The 7010 offers the same benefits on wood roofs as it does when used in a metal roofing application.  It has a Class A fire rating in accordance with ASTM E84.



Click here for Enkamat 7008/7010 details



EnkaRetain & Drain 3111

EnkaRetain & Drain 3111 is one of a new generation of products designed specifically for vegetated roofs. This multi-function composite consists of a 50% post-industrial recycled polypropylene drainage core of fused, entangled filaments and a specially formulated water retention fabric bonded to one side. The entangled filaments are molded into a square waffle pattern that maintains the flexible design of other Enkadrain products. The composite water retention fabric consistsof a 8 oz/yd² - 100% post consumer recycled non-woven polyester fabric mechanically bonded to a 12 oz/yd² layer of synthetic hydrophilic (water) absorbent mat. The absorbent mat is designed to hold 10 to 12 times its unit weight of water. It is a very strong, durable composite that is extremely resistant to puncture and tearing. The composite is inert to biological degradation and naturally encountered chemicals, alkalis, and acids.

Click here for EnkaRetain & Drain 3111 Details

Buy Plastic Now from GPS



______________________________________________

Enkadrain 3611R- 2 Leeds Points, Made from post recyled polypropylene

3611R EnkadrainEnkadrain 3611R is one of a new generation of environmentally conscious Enkadrain products.This drainage composite consists of a post-industrial recycled polypropylene drainage core of fused, entangled filaments and a geocomposite fabric bonded to one side. The entangled filaments are molded into a square waffle pattern that maintains the flexible design of other Enkadrain products. This product, because it exceeds 40% post-industrial recycled content, can help contribute up to 2 LEED points when used in conjunction with other recycled content products. Enkadrain 3611R can contribute towards additional LEED points when used with a green roof by reducing stormwater runoff, heat islands and energy consumption.

***Note, color of the product may vary.***

Click here for details

Click here for Spanish

Buy Enka Drain



____________________________________________________________________________

Enkadrain 3811R-Leed Points- Environmentally Friendly-Made from recycled Polypropylene!

3811R Enkadrain

Enkadrain 3811R is one of a new generation of environmentally conscious Enkadrain products.This drainage composite consists of a post-industrial recycled polypropylene drainage core offused, entangled filaments and a geocomposite fabric bonded to each side. The entangled filaments are molded into a square waffle pattern that maintains the flexible design of other Enkadrain products. This product, because it exceeds 40% post-industrial recycled content, can help contribute up to 2 LEED points when used in conjunction with other recycled content products. Enkadrain 3811R can contribute towards additional LEED points when used with a green roof by reducing stormwater runoff, heat islands, and energy consumption. The second fabric eliminates the need for protection board and stops penetration and migration of bitumen membrane.

***Note, color of the product may vary.***

Click here for Enkadrain 3811R



______________________________________________________________________________

_____________________________________________________________________________

Enkadrain® 3615R Colbond Building Products - Drainage-40% recycled content

Enkadrain 36`5R

Enkadrain 3615R is one of a new generation of environmentally conscious Enkadrain products.This drainage composite consists of a post-industrial recycled polypropylene drainage core offused, entangled filaments and a geocomposite fabric bonded to one side. The entangled filaments are molded into a square waffle pattern that maintains the flexible design of other Enkadrain products. This product, because it exceeds 40% post-industrial recycled content, can help contribute up to 2 LEED points, when used in conjunction with other recycled content products. Enkadrain 3615R can contribute towards additional LEED points when used with a green roof by reducing stormwater runoff, heat islands and energy consumption.

***Note, color of the product may vary.***

Click here for 3615R details

Click here for 3615R details in Spanish



________________________________________________________________________________________________________________________________________________

EnkaRain Drain - Colbond commercial rainscreens

EnkaRain Drain 9714 combines a 95% open V-Groove matrix for continuous water flow and a filter fabric that prevents mortar or stucco from closing off the drain cavity. In applications where a filter fabric is not required, Enkamat 7004 and 5006 can be used.

Buy Plastic Now at GPS

  _______________________________________________________________________________________________________________

Enkasonic 9110 is a 0.4" (10mm) thick composite of extruded nylon filaments forming a three dimensional core that has a nonwoven fabric heat bonded to its upper surface. The durable, yet pliable, construction of Enkasonic obstructs both structural and air borne sound transmission by its ability to convert and store vibrational energy.

Click here for Enkasonic 9110

Foundation Wall Geocomposit Drains- Enkadrain 3000R

Enkadrain 3000R  is a geocomposite drain fesigned for foundation walls.  It is designed to relieve hydrostatic pressure in soils abutting below grade structures. Enkadrain provides a lightweight and predictable drainage solution compared to traditional sand and gravel drains.

Using Enkadrain 3000R is an eco-friendly building product with multiple benefits:

          • Flexible and conformable
          • Proven and predictable flow rates
          • Protects external waterproofing layer
          • Backfill directly against matting
          • No sharp edges - safer for installers to handle
          • Made with post-industrial recycled content
          • 20 Year performance guarantee

Enkadrain is available with a filter fabric on one or two sides. It is a fast and reliable way to install effective drainage in vertical applications.
